Journeyman Electrician Glossary: Essential Terms and Definitions

Ever feel like you’re drowning in jargon on the jobsite or in the office? This isn’t just another list of electrical terms. This is a Journeyman Electrician’s survival guide, cutting through the noise to give you the definitions and practical applications you need today. We’ll cover the key terms you’ll encounter daily, from conduit fill calculations to grounding electrode systems, giving you the confidence to speak the language of the trade fluently. This isn’t a textbook; it’s a cheat sheet crafted by someone who’s been in the trenches.

What You’ll Walk Away With

• Definitions of 20+ essential Journeyman Electrician terms, explained with real-world examples.
• A “Language Bank” of phrases to use when discussing complex electrical concepts with inspectors, clients, and other trades.
• A checklist for verifying compliance with key code requirements related to grounding and bonding.
• A list of common mistakes when applying electrical code and how to avoid them.
• A framework for understanding the different types of electrical drawings and specifications you’ll encounter on a project.
• A decision guide for selecting the appropriate type of conduit for various applications.
• A clear understanding of the responsibilities of a Journeyman Electrician.

Scope: What This Is and What It Isn’t

• This is: A practical glossary of terms used by Journeyman Electricians daily.
• This is: Focused on terms related to installation, troubleshooting, and code compliance.
• This isn’t: A comprehensive electrical engineering textbook.
• This isn’t: A guide to passing your Journeyman exam (though it will help!).

Essential Journeyman Electrician Terms

This section defines the core terms every Journeyman Electrician needs to know. Each definition is followed by a practical example to show how the term is used in the field.

Ampacity

Ampacity is the current, in amperes, that a conductor can carry continuously under the conditions of use without exceeding its temperature rating. Think of it as the conductor’s “safe carrying capacity.” For example, a 12 AWG THHN copper conductor typically has an ampacity of 30 amps, but this can be affected by ambient temperature and the number of conductors in a conduit.

Bonding

Bonding is the permanent joining of metallic parts to form an electrically conductive path that ensures electrical continuity and the capacity to conduct safely any fault current likely to be imposed. It’s about creating a low-impedance path for fault current. A common example is bonding metal conduit to a metal enclosure using bonding bushings and jumpers.

Circuit Breaker

A circuit breaker is a device designed to open and close a circuit by nonautomatic means, and to open the circuit automatically on a predetermined overcurrent without damage to itself. It’s a safety device that protects circuits from overloads and short circuits. For instance, a 20-amp circuit breaker protects a circuit wired with 12 AWG conductors from exceeding its ampacity.

Conduit Fill

Conduit fill refers to the percentage of the cross-sectional area of a conduit that is occupied by conductors. NEC Article 314 specifies the maximum allowable fill. For example, you can’t fill a conduit more than 40% with multiple conductors.

Demand Factor

The demand factor is the ratio of the maximum demand of a system, or part of a system, to the total connected load of the system or the part of the system under consideration. It’s used to calculate the actual load a system will likely draw, which is often less than the total connected load. For example, an apartment building might have a demand factor of 0.6, meaning the service only needs to be sized for 60% of the total connected load of all the apartments.

Equipment Grounding Conductor (EGC)

The equipment grounding conductor is the conductive path installed to connect normally non–current-carrying metal parts of equipment to the system grounded conductor or to the grounding electrode conductor, or both. It provides a low-impedance path for fault current back to the source. An example is the green or bare wire running with the circuit conductors inside a conduit.

Feeder

A feeder is all circuit conductors between the service equipment, the source of a separately derived system, or other power supply source and the final branch-circuit overcurrent device. It’s the “backbone” of the electrical system. For instance, a 480V feeder might run from the main switchboard to a distribution panel serving a specific area of a building.

Grounding Electrode Conductor (GEC)

The grounding electrode conductor is the conductor used to connect the system grounded conductor or the equipment to a grounding electrode or to a point on the grounding electrode system. It connects the electrical system to the earth. A common example is the copper wire running from the neutral bus in the service panel to a ground rod.

Ground Fault Circuit Interrupter (GFCI)

A GFCI is a device intended for the protection of personnel that functions to de-energize a circuit within an established period of time when a current to ground exceeds some predetermined value that is less than that required to operate the overcurrent protective device of the supply circuit. It protects people from electrical shock. GFCIs are required in bathrooms, kitchens, and outdoor locations.

Neutral Conductor

The neutral conductor is the conductor connected to the neutral point of a system that is intended to carry current under normal conditions. It’s typically identified by a white or gray color. In a 120/240V system, the neutral conductor carries the unbalanced current back to the source.

Overcurrent Protection

Overcurrent protection is the process of protecting electrical circuits and equipment from excessive current flow, which can cause overheating and damage. This is typically achieved using circuit breakers or fuses. For example, a 15-amp circuit breaker provides overcurrent protection for a circuit wired with 14 AWG conductors.

Raceway

A raceway is an enclosed channel designed expressly for holding wires, cables, or busbars, with additional functions as permitted in this Code. It provides physical protection for conductors. Examples include conduit, electrical metallic tubing (EMT), and cable trays.

Service

The service is the conductors and equipment for delivering electric power from the serving utility to the wiring system of the premises served. It’s the point where the utility’s responsibility ends and the customer’s begins. For example, the service includes the service drop or lateral, the meter, and the service entrance conductors.

Short Circuit

A short circuit is an abnormal connection of relatively low impedance, whether made accidentally or intentionally, between two points of different potential in a circuit. It causes a large and rapid increase in current flow. For instance, if a hot wire comes into contact with a grounded metal enclosure, it creates a short circuit.

Transformer

A transformer is an electrical apparatus for changing the voltage of alternating current. It can step up or step down voltage. For example, a transformer might step down 480V to 120/240V for use in a commercial building.

Voltage Drop

Voltage drop is the decrease of voltage along a conductor due to impedance. Excessive voltage drop can cause equipment to malfunction. NEC recommends limiting voltage drop to 3% for feeders and 5% for branch circuits. For example, if the voltage at the source is 120V, the voltage at the end of the circuit should be no less than 114V.

Working Clearance

Working clearance refers to the space required around electrical equipment to allow for safe operation and maintenance. NEC Article 110.26 specifies the required working clearances based on voltage and other factors. For example, a panel operating at 480V might require 3 feet of working clearance in front of it.

Arc Flash

Arc flash is a dangerous condition associated with the release of energy caused by an electrical arc. It can cause severe burns and other injuries. Proper PPE, such as arc-rated clothing and face shields, is required when working on energized equipment.

Total Harmonic Distortion (THD)

THD is a measure of the harmonic content present in a voltage or current waveform. Excessive THD can cause overheating of equipment and other problems. It’s often caused by nonlinear loads such as electronic ballasts and variable frequency drives.

Transient Voltage Surge Suppressor (TVSS)

A TVSS is a device designed to protect electrical equipment from transient voltage surges, such as those caused by lightning or switching operations. It diverts the surge current to ground. TVSS devices are often installed at the service entrance and at distribution panels.

Language Bank: Talking Like a Pro

Use these phrases to communicate effectively with inspectors, clients, and other trades. These phrases are clear, concise, and demonstrate your knowledge of electrical concepts.

Use this when discussing conduit fill with an inspector:

“I’ve calculated the conduit fill per NEC Table C.1 and it’s under the 40% limit for multiple conductors.”

Use this when explaining the need for GFCI protection to a client:

“GFCI protection is required by code in wet locations to protect against electrical shock. It’s a critical safety measure.”

Use this when coordinating with other trades about equipment grounding:

“I’ll ensure that all metallic parts are properly bonded to the grounding system to provide a low-impedance fault current path.”

Use this when discussing voltage drop with a project manager:

“I’ve calculated the voltage drop for this circuit and it’s within the recommended 5% limit to ensure proper equipment operation.”

Use this when explaining the purpose of a transformer:

“This transformer steps down the voltage from 480V to 120/240V to provide power for lighting and receptacles.”

Use this when discussing overcurrent protection with a colleague:

“The circuit breaker is sized to protect the conductors from overloads and short circuits, preventing overheating and damage.”

Use this when explaining the importance of working clearance:

“We need to maintain the required working clearance around the panel to ensure safe access for operation and maintenance.”

Use this when discussing arc flash safety:

“We need to wear the appropriate PPE, including arc-rated clothing and a face shield, when working on energized equipment to protect against arc flash hazards.”

Use this when discussing THD issues:

“The THD levels are elevated due to the nonlinear loads. We should consider harmonic filters to mitigate the problem.”

Use this when discussing surge protection:

“We’ll install TVSS devices at the service entrance and distribution panels to protect against voltage surges from lightning or switching operations.”

Use this when discussing bonding:

“All metal conduit sections and enclosures must be properly bonded to ensure a continuous, low-impedance ground fault path.”

Use this when discussing ampacity:

“We need to verify the conductor ampacity based on the ambient temperature and the number of conductors in the raceway to ensure it can safely carry the load.”

Quick Checklist: Grounding and Bonding Verification

Use this checklist to ensure compliance with key code requirements for grounding and bonding. These are critical for safety and proper system operation.

1. Verify the grounding electrode system is complete and properly installed. Purpose: Ensures a connection to earth for fault current dissipation.
2. Confirm the grounding electrode conductor (GEC) is properly sized and connected. Purpose: Provides a low-impedance path to ground.
3. Ensure all metallic enclosures and raceways are bonded together. Purpose: Creates electrical continuity and a path for fault current.
4. Verify the equipment grounding conductor (EGC) is installed in each circuit. Purpose: Provides a low-impedance path for fault current back to the source.
5. Check that bonding jumpers are used around concentric and eccentric knockouts. Purpose: Maintains electrical continuity across the enclosure.
6. Confirm that bonding bushings are used on service entrance conduits. Purpose: Provides a low-impedance bonding connection.
7. Verify that all ground connections are tight and corrosion-free. Purpose: Ensures a reliable electrical connection.
8. Ensure that GFCI protection is provided in required locations. Purpose: Protects personnel from electrical shock.
9. Check that surge protection devices (TVSS) are installed at the service entrance and distribution panels. Purpose: Protects equipment from voltage surges.
10. Confirm that the neutral conductor is properly identified (white or gray). Purpose: Ensures correct wiring and polarity.
11. Verify that the neutral conductor is only grounded at the service entrance. Purpose: Prevents circulating ground currents.
12. Ensure that the bonding and grounding systems are separate from the neutral conductor downstream of the service entrance. Purpose: Prevents ground loops and ensures proper operation of overcurrent devices.

Common Mistakes: Avoid These Code Violations

Here are some common mistakes when applying electrical code and how to avoid them. Learning from others’ errors can save you time and prevent costly rework.

1. Improper conduit fill: Overfilling conduits can damage conductors and cause overheating. Use conduit fill calculators and NEC tables to determine the maximum number of conductors allowed.
2. Incorrect grounding electrode conductor (GEC) size: Using the wrong size GEC can compromise the grounding system. Refer to NEC Table 250.66 to determine the correct size based on the size of the service entrance conductors.
3. Failure to bond metallic enclosures: Not bonding metallic enclosures can create a shock hazard. Use bonding bushings and jumpers to ensure electrical continuity.
4. Improper GFCI protection: Failing to provide GFCI protection in required locations can result in electrical shock. Check NEC Article 210.8 for GFCI requirements.
5. Using the neutral conductor as a grounding conductor: This is a code violation and can create a dangerous situation. Keep the neutral and grounding systems separate downstream of the service entrance.
6. Overloading circuits: Exceeding the ampacity of a circuit can cause overheating and fires. Calculate the load and size the circuit accordingly.
7. Ignoring voltage drop: Excessive voltage drop can cause equipment to malfunction. Calculate voltage drop and use larger conductors if necessary.
8. Failing to provide working clearance: Not maintaining the required working clearance around electrical equipment can create a safety hazard. Refer to NEC Article 110.26 for working clearance requirements.

Understanding Electrical Drawings and Specifications

A Journeyman Electrician must be able to read and interpret electrical drawings and specifications. This section outlines the different types of drawings and specifications you’ll encounter on a project.

• Single-line diagrams: Show the electrical system in a simplified form, using symbols to represent components such as transformers, circuit breakers, and switches.
• Panel schedules: List the circuits in each panelboard, including the breaker size, load description, and conductor size.
• Lighting plans: Show the location of lighting fixtures and the type of fixture to be installed.
• Power plans: Show the location of receptacles and other power outlets.
• Control diagrams: Show the wiring and connections for control systems, such as HVAC and fire alarm systems.
• Specifications: Provide detailed information about the materials and equipment to be used on the project, including manufacturer, model number, and performance requirements.

Decision Guide: Choosing the Right Conduit

Selecting the appropriate type of conduit is crucial for a safe and code-compliant installation. Here’s a decision guide to help you choose the right conduit for various applications.

• Rigid Metal Conduit (RMC): Provides the highest level of physical protection and is suitable for direct burial and hazardous locations.
• Electrical Metallic Tubing (EMT): Lightweight and easy to install, suitable for indoor use in dry locations.
• Intermediate Metal Conduit (IMC): Thinner and lighter than RMC, but still provides good physical protection.
• Flexible Metal Conduit (FMC): Used for short runs and connections to motors and other equipment where flexibility is needed.
• Liquidtight Flexible Metal Conduit (LFMC): Used in wet locations and where flexibility is needed.
• Rigid PVC Conduit: Lightweight, corrosion-resistant, and suitable for direct burial.

Responsibilities of a Journeyman Electrician

A Journeyman Electrician has a wide range of responsibilities, including: These responsibilities require both technical skill and a commitment to safety.

• Installing electrical systems and equipment: This includes wiring, conduit, panels, lighting, and other components.
• Troubleshooting electrical problems: This involves diagnosing and repairing electrical faults and malfunctions.
• Interpreting electrical drawings and specifications: This requires a thorough understanding of electrical symbols and codes.
• Ensuring compliance with electrical codes and standards: This is essential for safety and legal compliance.
• Maintaining a safe work environment: This includes following safety procedures and using appropriate PPE.
• Supervising and training apprentice electricians: This involves mentoring and guiding the next generation of electricians.

FAQ

What is the difference between grounding and bonding?

Grounding connects the electrical system to the earth, providing a path for fault current dissipation. Bonding connects metallic parts together to create a low-impedance path for fault current. Both are essential for safety and proper system operation.

What is the maximum allowable voltage drop for a branch circuit?

NEC recommends limiting voltage drop to 5% for branch circuits. Excessive voltage drop can cause equipment to malfunction. For example, if the voltage at the source is 120V, the voltage at the end of the circuit should be no less than 114V.

What is the purpose of a GFCI?

A GFCI protects people from electrical shock by de-energizing a circuit when it detects a current leakage to ground. It’s required in wet locations such as bathrooms, kitchens, and outdoor areas.

How do I calculate conduit fill?

Use conduit fill calculators and NEC tables to determine the maximum number of conductors allowed in a conduit. The calculation is based on the cross-sectional area of the conductors and the conduit.

What is the difference between a feeder and a branch circuit?

A feeder is the “backbone” of the electrical system, running from the service equipment to the final branch-circuit overcurrent device. A branch circuit is the circuit that extends from the final overcurrent device to the outlets and equipment.

What is the purpose of an equipment grounding conductor (EGC)?

The EGC provides a low-impedance path for fault current back to the source, allowing the overcurrent device to trip and clear the fault. It’s typically a green or bare wire running with the circuit conductors.

How do I size a grounding electrode conductor (GEC)?

Refer to NEC Table 250.66 to determine the correct size GEC based on the size of the service entrance conductors. The GEC connects the electrical system to the earth.

What is the purpose of a surge protection device (TVSS)?

A TVSS protects electrical equipment from transient voltage surges, such as those caused by lightning or switching operations. It diverts the surge current to ground. TVSS devices are often installed at the service entrance and at distribution panels.

What is Total Harmonic Distortion (THD)?

THD is a measure of the harmonic content present in a voltage or current waveform. Excessive THD can cause overheating of equipment and other problems. It’s often caused by nonlinear loads such as electronic ballasts and variable frequency drives.

What is working clearance and why is it important?

Working clearance is the space required around electrical equipment to allow for safe operation and maintenance. NEC Article 110.26 specifies the required working clearances based on voltage and other factors. Maintaining adequate working clearance is essential for safety.

What is arc flash and how can I protect myself?

Arc flash is a dangerous condition associated with the release of energy caused by an electrical arc. It can cause severe burns and other injuries. Proper PPE, such as arc-rated clothing and face shields, is required when working on energized equipment.

What are the different types of electrical drawings and how are they used?

Electrical drawings include single-line diagrams, panel schedules, lighting plans, power plans, and control diagrams. They provide detailed information about the electrical system and are used for installation, troubleshooting, and maintenance.

---
